SeaVee 322z Options

The SeaVee 322z represents a new approach to deck layout and ergonomics by placing the bait wells in the corners and extending the rear cockpit as well as adding storage capacity. Notable options include up to 4 live wells, an upper station with full controls, and a range of leaning post and t-top designs. Upgrading with Luxury Edition options (LE) adds molded-in forward seating or a variety of removable rear benches.

Specifications

  • LOA – 32’ 9”
  • Beam – 9’ 6”
  • Weight w/o Engines – 6,900 lbs.
  • Hull Draft – 20”
  • Hull Deadrise – 22°
  • Fuel Capacity – 312 gal.
  • Fresh Water – 39 gal.
  • Waste – 19 gal.
  • Max Engines – 2
  • Max HP – 1000 hp
  • Fwd Fishbox – 129 gal.
  • Fwd Fishbox / Live Well – 41 gal.
  • Fwd Wing Boxes – 2 x 51 gal.
  • Aft In Deck Fishbox / Live Well – 88 gal.
  • Transom Corner Live Wells – 2 x 40 gal.
  • Aft Storage Boxes – 2 x 17.5 gal.
  • Aft Lift Out Boxes 2 x 7 gal.

Standard Features

  • Dual aft corner 40 gallon live wells
  • Integrated platform with transom door
  • Fully insulated fishboxes (2)
  • Hydraulic steering
  • High performance trim tabs
  • Dual water separators
  • Large dual card compass
  • Dual automatic bilge pumps
  • Dual marine AGM batteries
  • Tinned wiring
  • Electrical breaker panels
  • Sliding Door Console
  • Navigation lighting
  • 1/4” Coated Aluminum Fuel Tanks
  • Heavy duty rub rail
  • Anchor locker / Windlass Compartment
  • Pop up cleats (6)
  • Rod Holders (4)
  • Under deck dry storage
  • Self-bailing cockpit with non-skid deck
  • Center Console with storage compartment
  • Lockable rod storage
  • 10 year hull warranty

Deck Layout

Deck Layout Legend

  1. Live Well
  2. Aft Storage With Molded Lift Out Storage Tubs
  3. Aft Storage W/ Integral Molded Recesses For 5 Gal Bucket Storage

Gel Coat Color Options

  • White
  • Teal
  • Light Blue
  • Dark Blue
  • Black
  • Red
  • Light Yellow
  • Dark Yellow
  • Gray

Available 322z Options
